180 t^OTTON SPINNING, 141 rods, L^. The nipper cam makes one revolution to one of tliecylinder and, at each revolution, the opening and closing ofthe nipper and cushion plate takes place which corresponds to themovements of the cylinder. To follow these movements, Figs. 117, 118, 119 and 120have… … P Fig. 1L8. Fig. 119. Sections showing Nipper and Cusliion Plate. fluted segment and liaJf lap. Fig. 120 is a diagram of the nippercam showing certain points wliich correspond to the figures onthe timing dial. In Fig. 117, it is assumed that the needles have finishedcombing and the nipper and…
