ib- L \ and-key construction is aban- y I doned, and the half-brasses are held together in a jaw by bolts parallel to the length of therod. These bolts have to with-stand the push and pull of therod, but they make a very stiffand strong stub particularly welladapted for crank-pins of con-siderable… … CROSS-HEAD GUIDES AND CONNECTING-RODS. 325 Another form of stub is known as the round-end stub. Theend of the connecting-rod has a tapering hole within whichis inserted a bronze bushing which fits the taper on its outsideand the cylindrical pin on its inner side. As wear takesplace, the split in…
