Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 367
hen there are several cylinders side by side the arrange-ment of the crank-shaft must conform to this condition. Forthe ordinary cross-compound engine where the power is takenoff from a central fly-band-wheel, as in Fig. 95, the cranks 329 330 MECHANICAL ENGINEERING OF POWER PLANTS. will overhang.…
Mechanical engineering · Steam power plants
