Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 398
Fig. 307.recently worked out for this purpose in places to which itcan be satisfactorily applied. It is called the steam-loopand is shown in Fig. 308. The pipe from the bottom of … Fig. 308.the separator becomes a species of siphon, whose length ofleg is depended upon to move the water in it by the dif-ferences of density of the water in the two legs. In the 362 MECHANICAL ENGINEERING OF POWER PLANTS drop-leg of the loop, which is connected to the boiler belowrthe water-line,…
Mechanical engineering · Steam power plants
