Fig. 334. THE STKAM-BOILER. GENERAL CONSTRUCTION. 403 may be either chain or stagger as respects the arrangementof the rivets. In chain-riveting the rivets are behind eachother in the two rows. The objection to the lap-joint is thetendency to flex the plates at the passage from two thick- … FiG. 336. nesses to one when the pull on each plate seeks to opposeitself to that exerted in the line of the other (Fig. 323). Thetreble-riveted joint (Fig. 334) gives a longer lap and moreplate area and more rivet-shearing area, as well as a stiffer
