Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 466
neck (Figs. 365 and 371). TYPES OF BOILERS. 429 The flanges of the neck return some strength and stiffness tothe shell. It is more convenient, if this is to be done, tomake the dome a horizontal drum (Fig. 373). (3) To use a horizontal drum or pipe of large diameteroverhead, to which the boiler… … Fig. 365.this a drainage-connection may remove any entrained waterwhich may be carried through neck or nozzle by high velocityof steam-currents. Fig. 367 will illustrate this arrangementwhen the drum is transverse, and is really a large pipe merelyjointed to each boiler by piping which allows of…
Mechanical engineering · Steam power plants
