Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 65
engine is not so completely andinflexibly secured to its foundation and a deeper foundation isthereby required, or an unequal settling of such foundationwill occur, if the concentrated load is not sufficiently widelydistributed. Fourth, when the piston-rod protrudes from thebottom head of such… … make it very troublesome to make the stuffing-box tightenough to prevent leakage of water. THE MECHANISM OF ENGINES. 33 i8. Inverted Vertical Engines.—The cylinder of a verti-cal engine can be arranged to have the cylinder supported uponsuitable frames above the crank and shaft, or the cylinder…
Mechanical engineering · Steam power plants
