Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 690
two other moving pieces. The crank-pin islubricated either by centrifugal force as shown in Fig. 506,whereby oil received near the centre of motion is carriedoutward through a pipe to the centre of the pin, and is theredistributed through a radial hole outwards upon the bearing-surface, or else a… … Fig. 505. wards upon the pin (Fig. 507). For the cross-head pin asimilar fixed cup is placed over the path of the cross-headhaving on its under side a piece of webbing or similar textilematerial upon which the oil drops and is spread. Illustrations ^54 MECHANICAL ENGINEERING OF POWER PLANTS. of…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
