Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 179
ines, the effect onthe mechanism of the steam part is not affected (Fig. 36), norif cylinders inclined to each other operate on a common pin(Figs. 22 and 96). 65. The Diagram of Steam Effort in a CompoundEngine.—It will be apparent that a diagram which shows thepressures on the piston of a… … SIMPLE AND COMPOUND ENGINES. 127
Mechanical engineering · Steam power plants
