Fig. 171. CAM AND RELEASE VALVE-GEAR. 205 depended on, or else there must be a roller or yoke oppositeto the first one to bring the rod back with a motion similar … Fig. 172.to that caused by the cam against the first roller. This out-side cam arrangement has the advantage that the rolleralways turns in the same direction. The two-roller or yoke
