Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 385
hen there are several cylinders side by side the arrange-ment of the crank-shaft must conform to this condition. Forthe ordinary cross-compound engine where the power is takenoff from a central fly-band-wheel, as in Fig. 95, the cranks 329 33° MECHANICAL ENGINEERING OF POWER PLANTS. will overhang.…
Mechanical engineering · Steam power plants
