ght or unbalanced effect ofthe mechanism. Some designers have built up cast-ironcounterweights upon a wrought-iron crank. Fig. 284 showsan arrangement of this sort. When there are two cylinders to work upon one crank-shaft and it is to be a continuous or double crankj thedoublecrank will be forged… … a lathe of sufficient size. Of course it is- not easy to forgesuch cranks with short distance between them, nor is it easy 334 MECHANICAL ENGINEERING OE POWER PLANTS. to get them truly at right angles. Built-up crank-shafts,where the crank-pins and lengths of shafting are separate orfastened…
