Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 416
Fig. 306. PIPING FOR THE ENGINE AND ITS ATTACHMENTS. 36 trifugal separator for a horizontal line of pipe. The heavierwater is thrown radially and caught in the receiver below.A substitute for the trap, forming a fifth system, has been … Fig. 307.worked out for use in places to which it can be satisfactorilyapplied. It is called the steam-loop and is shown in Fig.308. The pipe from the bottom of the separator becomes HORIZONTAL
Mechanical engineering · Steam power plants
