Marine engines; problems, notes and sketches. Additional to the text-book used in the instruction of naval cadets of the second class, United States Naval Academy (1899)
United States Naval Academy. Dept. of Marine Engineering · Annapolis : Dept. of Steam Engineering, U. S. Naval Academy · leaf 40
AL SEPARATOR. Art. 14.—(P. 123, S. & O.) Figs, no and in of the text-book show a type of separatorin common use. Another type, sometimes used in the U. S. PROBLEMS, NOTES AND SKETCHES. 37 navy, consists of a cylindrical chamber with vanes so arrangedas to give the entering steam a whirling… … (Fig. 1.^.) STEAAI TRAPS. Art. 15.—(P. 126. S. & O.) There are various types of steam traps in use in the U. S. navy.The trap shown on p. 126 of the text-book represents one type,being similar to the Nason trap. Another type consists of a chamber with an outlet valve oper-ated from the end of a…
Marine engines
