Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 458
Fig. 334. THE STEAM-BOILER. GENERAL CONSTRUCTION. 403 may be either chain or stagger as respects the arrangementof the rivets. In chain-riveting the rivets are behind eachother in the two rows. The objection to the lap-joint is thetendency to flex the plates at the passage from two thick- … Fig. 336. nesses to one when the pull on each plate seeks to opposeitself to that exerted in the line of the other (Fig. 323). Thetreble-riveted joint (Fig. 334) gives a longer lap and moreplate area and more rivet-shearing area, as well as a stiffer 3 Fig. 337. joint. The butt-joint with double…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
