Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 465
he stay-rod has been fastened to stay-bars on the heads by a pin-joint. Fig. 342 shows a form of 4-IO MECHANICAL ENGINEERING OF POWER PLANTS. this method where the stay-bars are relatively heavy forgingsof two to two and a half inches square, with lugs bump-weldedon the inside. The stay-rod ends in… … Fig. 343. irons are riveted to the head, and the stays pinned to them bypins in single or double shear; but in these arrangements theobliquity of the stay-rod indicates a prevalent arrangement formedium pressures. The inner end of the stay-rod in this case THE STEAM-BOILER. GENERAL CONSTRUCTION. 41I
Mechanical engineering · Steam power plants
