in a given ground-planand to secure more effective cooling of the flame or hot gasby a transfer of its heat to the walls of the flues which arecooled by the water which surrounds them. The gases turnupward in a space at the rear head of the boiler, which willbe called the back connection, and from… … m a TYPES OF BOILERS. 44l water-space. They will be made of boiler-plate, riveted orwelded, or (if not of too large diameter) of lap-welded boiler-tube. The necessary length of flue will be secured by joininglengths together either by lap- or butt-joints riveted, by weld-ing, or by the upset- or…
