Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 574
Fig. 441, They will then be arranged to open on vertical hinges, andwill be held shut by a common latch. In extension fronts itbecomes more convenient to make the opening to the smoke-box for inspection by a door turning upon a horizontal hingeat about the horizontal diameter. Figs. 436 to 446 and… … 5^6 MECHANICAL ENGINEERING OF POWER PLANTS. Fig. 461 show typical constructions covering these pointsand methods. Fig. 433 illustrates a type of extended front which hasreceived some approval among the pure-water conditions in
Mechanical engineering · Steam power plants
