Hutton, Frederick Remsen, 1853- [from old catalog] · New York, J. Wiley & sons; [etc., etc.] · leaf 467
a drainage-connection may remove any entrained waterwhich may be carried through neck or nozzle by high velocityof steam-currents. Fig. 367 will illustrate this arrangementwhen the drum is transverse, and is really a large pipe merelyjointed to each boiler by piping which allows of expansionwithout… … TYPES OF BOILERS. 431 ment-surface to pass into the steam-pipe through a numberof small holes in the interior pipe which is a prolongation ofthe steam-pipe inside the boiler. The gentle current intoeach opening prevents entrainment of water, because theaggregate area of openings is in excess of the…
Mechanical engineering · Steam power plants
