Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 596
The horizontal grate renders it more easy to keep the fireof even thickness at the front and back, and makes it slightlyeasier to withdraw the clinker and other solid matter which isto be drawn forward and out through the fire door in arrange- B OILER-SE TTING. 537 merits of this sort. The general… … Fig. 457-The level of the grate-bars with hand-firing should be soselected as to make the cleaning and coaling convenient to thefireman. This seems to be secured by having the top of thegrates from 24 to 30 inches above the general floor-level. Thedepth of the furnace or the length of the bar with…
Mechanical engineering · Steam power plants
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
