Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 713
Fig. 506. … Fig. 507. In large engines with many cylinders and multiple mechan-isms a practice has been followed of bringing all oil-cups to a MANAGEMENT AND RUNNING OF ENGINES. 655 few points and connecting these oil-cups by pipes to thevarious bearing-surfaces to be lubricated. In vertical enginesof the…
Mechanical engineering · Steam power plants
