Steam engines; a thorough and practical presentation of modern steam engine practice (1917)
Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 179
166 STEAM ENGINES … Fig. 97. Form of Wiper Crank Pin Oi A form of wiper crank pin oiler is shown in Fig. 97. The oilcup is attached to a bracket. The oil drops from the cup into the sheet of wicking or wire clothand is removed at each rev-olution of the crank pin bymeans of the cup which isattached to the end of…
Steam-engines
