Hutton, Frederick Remsen, 1853-1918 · New York, J. Wiley & sons; London, Chapman & Hall, limited · leaf 74
Fig. 15 make it very troublesome to make the stuffing-box tightenough to prevent leakage of water. THE MECHANISM OF ENGINES. 33; 18. Inverted Vertical Engines.—The cylinder of a verti-cal engine can be arranged to have the cylinder supported uponsuitable frames above the crank and shaft, or the… … Fig. 16. is known as the inverted vertical type. The general advan-tage of this arrangement is that the moving reciprocatingparts, which are those whose inertia or living force must betaken up by solid connection and for which the crank-pin mustprovide, are held to the ground through the…
Mechanical engineering · Steam power plants
