Modern mechanism, exhibiting the latest progress in machines, motors, and the transmission of power, being a supplementary volume to Appletons' cyclopaedia of applied mechanics (1892)
Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 774
Fitchburg, Mass.. is shown mFig. 3. The machine is designed for rolling accurately and in a short space of timea large variety of work which at present is turned out by more laborious and expensive pro-cesses, such as lathe turning, the customary methods of forging, and others. The machine ROLLS,… … Fig. 3.—The Simonds metal rolling macMne. by means of suitable fixtures, are a number of rollers, arranged to act as front, rear, andside supports and guides to cast-iron traveling platens, 0 0. They thus take the place of the ordinary slidingsurfaces, and, affordingonly rolling contact, re-duce…
Mechanical engineering
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
