s or four cylinders with the pumps below them onthe same rods, and yet the engine does not extend over sogreat an area of ground-plan. In the design exhibited inFig. 22 it will be observed that by the arrangement of the 40 MECHANICAL ENGINEERING OF POWER PLANTS. two cylinders the practical result… … not suffer as much from the disadvantages, neither does itbenefit as much from the advantages. The piston is apt towear the bore seriously from a tendency to dig into the metalat upper and lower corners. 21. Combined Horizontal and Vertical Engines. — Adesign of engine has been used for pumping or…
