^W^^^ Fig. 34. come about when the axes of the cylinders are parallel to eachother and the fly-wheel shaft in line with neither; in Fig. 35the beam is in line with the steam-cylinder, and in Fig. 36the beam loses its linear or conventional shape. 25. Objections to the Beam-engine.—The… … THE MECHANISM OF ENGINES. 51 First, those attaching to a transmission of the work throughso many joints indirectly to the crank-pin. Secondly, theobjection in marine practice to having the weight of the
