10 x 15 Manhole Fig. 40. Typical Layout or Boiler Tubes for R. T. Boilers. Boiler 60in Diameter44 Tubes 4Dia. Boiler 60 in Diameter54 Tubes 3 k Dia. Boiler 60 in Diameter74 Tubes 3 Dia. … 12 Braces Boiler 54 in DiameterTubes 4Dia. Boiler 54 in Diameter48 Tubes 3iDia. Boiler 54 in Diameter60 Tubes 3Dia,
