An illustration from Mechanical equipment of buildings; a reference book for engineers and architects, 1916, leaf 215 — ST Fig. 4. Dimension Drawing of Sturtevant Undergrate Blower. (Table 1.) Forced Draft for Large Plants. When several boilers are to be served with forced draftin a new plant, a duct system is installed beneath the boiler-room floor connected with one ormore fans, the outlets being located in front… … Fig. 5. Large radius curves should be employed in all cases and square-cornered turns avoided to preventexcessive friction. Ducts are designed for air velocities of 2000 to 3000 ft. per minute. The pressure loss maybe estimated, for a given layout, by the data given in the Chapter on Hot Blast…
