Mechanical equipment of buildings; a reference book for engineers and architects (1916)

Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 316

An illustration from Mechanical equipment of buildings; a reference book for engineers and architects, 1916, leaf 316 — e, is equal to 0.58pi as proven both by theory and experiment. This ratio 0.58 appliesto dry saturated steam. If the steam is highly superheated initially the ratio is about 0.55. STEAM TURBINES 301 THE IMPULSE TURBINE In a turbine of the pure impulse type the expansion and positive acceleration of… … Fig. 5. The Main Elements of the De Laval. Turbine.

Building · Heating · Ventilation

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
