Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 319
eaving the blade must clear the wheel. The steam must therefore for practical reasonsenter and leave the wheel at an angle. In the De Laval single pressure stage turbine the nozzle makes an angle a = 20° with thex — x axis of the wheel, as indicated by Fig. 6, 304 POWER PLANTS AND REFRIGERATION The… … Fig. 8. Details of Blades.
Building · Heating · Ventilation
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
