Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 416
-Level Jet Condenser. STEAM CONDENSERS 395 Condenser Head. The cool water being brought to the condenser inlet B is distributedaround the entire circumference through annular opening C and enters the head through helicaldistributing nozzles D. These nozzles give the water a rotary motion, and break… … Fig. 10. Cross-Section or Westinghouse Leblanc Low-Level Jet Condenser. should not exceed about 18 ft. While the nozzles D are of generous proportions, hand holesare provided so sticks, leaves or other debris which might be brought in with the water may beeasily removed. Water Pump. The mixture of…
Building · Heating · Ventilation
Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
