Mechanical equipment of buildings; a reference book for engineers and architects (1916)

Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 547

An illustration from Mechanical equipment of buildings; a reference book for engineers and architects, 1916, leaf 547 — Fig. 57. Exhaust Head.Cast Iron. Fig. 58. Climax Automatic CellarDrainer. to the outside of the separating chamber by centrifugal force when the direction of the steamcurrent is suddenly altered. In this way separation is effected, and the water and oil drainedaway by suitable drips. The steam and…

Building · Heating · Ventilation

Internet Archive · University of Toronto, Robarts Library · Public Domain Mark 1.0. Free to use for anything.
