s off the steam or water entering D and passing to the radiator through outlet E.If the pressure in F is relieved the spring G will open the valve and flow will be re-estabhshed. Iron body valves of larger size for heav> duty are also equipped with pneumatic diaphragms. Metal Diaphragm Valves.… … D Fig. 16. ■Sectional View of Diaphr.\gm Valve.
