An illustration from Mechanical equipment of buildings; a reference book for engineers and architects, 1916, leaf 594 — Fig. 26. Interiob of the Erwood Swing-Gate Valve. The Dotted Lines ShowTHE Swing-Gate Partly Open. PIPE, FITTINGS, VALVES, COVERINGS AND ACCESSORIES 567 Ordinary plug cocks (Fig. 28) on blow-off lines are satisfactory for low pressure heating work,and specially designed cocks or asbestos-packed… … Fig. 26a. Application of Erwood Swing-Gate Valve.
