s and Guide Vane Passages.A loss of kinetic energy occurs both in the blades andguide vanes due to the frictional resistance offered to thepassage of the steam. Let Wi = velocity at inlet to blades relative to theblade or the absolute velocity at inletto guide vanes.We = velocity at outlet of… … Fig. 15. Single Pressure Stage-Velocity Stages. (1.0 - i,) = V 1.0 - 4^2 ^g -Two (17) An energy loss of 10% (i/z = 0.10) in both blades and guides is frequently assumed in tenta-tive designs for two or more velocity stages. This loss is a function of the velocity and is there-fore not a constant.…
