ults, when reduced to scale, as the lengths ofordinates in the construction of the bending-moment diagram.In this instance the linear scale will be taken as o.i inch = i foot,and the bending-moment scale as i inch = 1000 pounds-feet. For the purpose of constructing the bending-moment diagramthese… … BENDING-MOMENT AND SHEAR DIAGRAMS 53 At the section 2 feet to the right of the left support M = 730 X2 — 20X10X5 — 200 X 6 = — 740 Ibs.-ft. At the section 4 feet to the right of the left support M = 730 X4 — 20X12X6 — 200 X 8 = — i2olbs.-ft. At the section 6 feet to the right of the left support M…
