micals or ddbris, and absorb a maximum amount of heat. STEAM CONDENSERS 409 Fig. 26 shows a condenser for large installations, designed along the lines indicated by thepreceding paragraphs. Fig. 27 shows a combination of surface condenser and wet vacuum pump of the reciprocat-ing type such as used… … Fig. 28. Wheeler Surface Condenser Installation. being employed. The vacuum pump and centrifugal circulating pump in this installation areboth driven by a vertical high-speed engine. Fig. 29 shows a typical Westirighouse surface condenser installation in which a separateair pump is employed to…
