Mechanical equipment of buildings; a reference book for engineers and architects (1916)
Harding, Louis Allen, Willard, Arthur C. (Arthur Cutts), 1878-1960 · New York Wiley · leaf 664
= 3200 lb. to betaken care of in bending by the head shaft. The unbalanced load at pitch line of sprocketsproducing the torsional moment H = 320 -f- lOO^o (for shock) = 640 lb. T. J- » 1600 Bending moment B = X 8 = 6,400 m. lb. Torsional moment T = 640 X 16 = 10,240 in. lb. From diagram Fig. 30…
Building · Heating · Ventilation
