Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice (1922)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 42

An illustration from Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice, 1922, leaf 42 — Fia. 12.—Vacuum Gage Tester. SCALES AND PRESSURE GAGES 25 method is convenient but the friction of the plunger preventstrue records. Fig. 13 shows an apparatus of this type. ,, Weights -forf Measuring Pressure b … | WM for Adjustment^ O

Mechanical engineering
