Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice (1922)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 63

An illustration from Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice, 1922, leaf 63 — Fig. 28.—Van Winkle Dynamometer. … Fie. 29.—Central Laboratory Dynamometer. completed causing a click in a telephone receiver. The right-handbrush is stationary, but the one on the left is so arranged that itmay be swung around the shaft. In operation, the latter is DYNAMOMETERS 47 manipulated until a click is heard in the receiver,…

Mechanical engineering

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
