Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice (1922)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 91

An illustration from Mechanical laboratory methods; the testing of instruments and machines in the mechanical engineering laboratory and in practice, 1922, leaf 91 — meter of the disc.By using different discs, a reducing wheel may thus be operatedthrough any desired stroke. The reducing wheel to be tested is connected to an indicatorand the whole set in place on the tester. The wheel may thenbe operated at any required conditions of stroke, speed, and… … Driving Shaft-Variable Speed

Mechanical engineering
