Mechanical laboratory methods; a testing of instruments and machines in the mechanical engineering laboratory and in practice (1918)

Smallwood, Julian Chase · New York, D. Van Nostrand company · leaf 67

An illustration from Mechanical laboratory methods; a testing of instruments and machines in the mechanical engineering laboratory and in practice, 1918, leaf 67 — stantionarydial. The dial is arranged to indicate horse-power direct. Another spring dynamometer, made by the Central LaboratorySupply Company, is shown by Fig. 29. Two shafts are connectedby a spring through which the power to be measured is passed.These shafts are provided with discs arranged as… … Drlver6horff

Mechanical engineering laboratories
