424. SIMPLE GAS OR GASOLINE ENGINE.—A, inletvalve ; E, exhaust valve; gasoline enters by gravity at G, regulatedby a faucet. Air enters at B by the suction of the piston, atomizingthe gasoline as it drops into the air chamber. The tube igniter isheated by a gasoline burner beneath the bell mouth.…
