E 447. CARBURETTERfor making air gas fromgasoline; non-freezing. A,plan — a zig-zag series ofchambers with spaces be-jK tween for air circulation tokeep its vaporizing wallswarm; B, a vertical section; c, c, c, open spaces. Canton or otherflannel wrapped over wire gauze frames is pushed into the… … 448. AUTOMATIC OILER.—Much in use on explosive motors. Shaft <r, andcrank <^, with the dip wire d, are revolved bya belt dropping the oil on the wiper e, intothe small tank/, from which it flows to thecylinder.
