448. AUTOMATIC OILER.—Much inuse on explosive motors. Shaft r, andcranky, with the dip wire d, are revolved bya belt dropping the oil on the wiper e, intothe small tank/, from which it flows to thecylinder. … UNIFORM AUTOMATIC OILER.—Used on gas engines. The shaft, driven by abelt from the valve-gear shaft of the engine,carries two hooks and dip wires, one ofwhich raises the oil from the variable levelbelow to a constant level oil reservoir, fromwhich the second hook and dip wire feedthe wiper that…
