634. TROMPE OR HYDRAULICAIR BLAST.—One of the early devicesfor furnishing an air blast to a forge.The falling column of water draws in airthrough the small inclined orifices at d^carrying it into the reservoir e^ where itseparates, and is discharged through thetuyere pipe at b. The outlet at i… … 635. AIR COMPRES-SOR.— Elevation of duplextype, showing connectingrod and yoke frame. Cla5rton model. AIR POWER APPLIANCES. 171
