Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1914)

Hiscox, Gardner Dexter, 1822?-1908 · New York, N. W. Henley Publishing · leaf 105

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1914, leaf 105
held in place byan annular follower and springs. 244. BALANCED EXPANSION JOINT for steam pipesSmith pat. Referring to the cut, it will be noticed that the inner tube has an increased diameteror ring about halfwayalong its length. Thisforms a shoulder or pistonat the end next to the bot-tom of the… … STEAM POWER APPLIANCES. 103 j:t:l

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
