Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing co. · leaf 234
865. BICYCLE GEAR.—Transmission by fore and aft shaft with pin-tooth gearing. Sagar model. 866. Pin-tooth wheel andpinion. m … 867. BICYCLE CRANK.—A devicefor shortening the up-crank stroke. Theeccentrics are fixed to the frame. Thecranks and eccentric straps revolve onball bearings, carrying by link connectionthe secondary crank shaft and sprocketwheel. 868. Horizontal plan. 869. SWINGING BALL-BEARINGBICYCLE…
Mechanical movements
