Cassells' carpentry and joinery (1907)
Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 141
Fig. 459.—Heel Strapand Bolt. Fig. 458.—Conventional View showing Joints at Foot of Truss,at Pole Plate, and Rafters. TIMBER ROOFS. 123Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
