1074. SIX RADIAL GROOVED TRAMMEL and triangular shaft arms, driving or beingdriven by a shaft out of line. The frictionrollers give freedom of motion to either gear. XxZy^ZZ^^i^ /C \l Va- ;.. Pr ~1 1 iiO 1075. RECTILINEAR RECIPROCAT-ING MOTION of a bar, from continuous cir-cular motion of a bent… … 1076. ROCKING MOTION, from a contin-uous 7otary motion of the crank shaft A. 1076a. PAIR OF TOE LEVERS.—Bell-crank order. A and B, fulcrums of thelevers ; E, handle ; C, curved toes. Thisprinciple is used as a valve gear. 1077. WIPER CAM for stamp mills. A, the wiper;D, flanged chock, allowing the…
